V2H SOM
Powered by Renesas' RZ/V2H processor, boasts a Quad Cortex®-A55 (1.8GHz) CPU and an integrated AI accelerator, DRP-AI3, optimized for vision-based tasks. This module is a cost-effective choice for a range of AI-driven vision applications. It supports 4 x 4-lane MIPI CSI-2 connections, enabling the parallel (or concurrent) attachment of up to four cameras. Additionally, the full module provides customizable options such as onboard Wi-Fi/Bluetooth, various memory and storage capacities, and PHY configurations, allowing users to tailor the system to their specific needs.
Core benefits
Small form factor
Complete solution including HW&SW
Flexible & modular platform
Advanced Security
No items found.
Multi camera connectivity, up to 4 x 4-lane MIPI CSI
Quad core A55 + Dual cortex R8 + Cortex M33
Built in AI accelerator
4K encoder/decoder
Various communication / storage / network interfaces
Accelerators engines
On-chip SRAM
Audio
Analog/digital converter(ADC)
Internal temperature sensors
Security
Specification
Description
- CPU | RZ/V2H, 4xA55+M33+2xR8, VPU, NPU, GPU, ISP^^
- Memories | LPDDR4/4X-3200, 8 or 16 GByte^^eMMC 4.51, HS200^^QSPI flash 64 Mbyte^^
- Connectivity | 2 x USB 3.2 Gen2x1 (10Gbps)^^2 x USB 2.0^^PCIe: Gen3, 2x 2-Lane or 1x 4-Lane^^GbE: 2 x RGMII^^2 x SDIO (4-bits)
- Camera | 4 x 4-lane 2.1Gbps MIPI CSI interface^^ISP^^
- Display | 1 x 4-lane DSI, with touch I/F^^
- Audio | 5 x I2S^^2 x PDM 3-channels^^3 x SPDIF^^
- Other I/Fs | 3 x SPI^^ 9 x I2C^^1 x I3C^^10 x SCI (UART/I2C/SPI)^^6 x CAN-FD^^50 x GPIO^^8 x ADC^^
- Power | Single power input 3.0-5.5v^^Integrated PMICs^^
- Mounting | 3 x DF40C-120DP-04V connectors^^
- Dimensions | 36 x 58 x 6mm^^
